Electric fine grinding for wood chips and prepared biomass materials.
Technical configuration is confirmed only after reviewing your raw material and project requirements.
The electric wood hammer mill processes prepared wood pieces and chips into uniform wood powder for pellet production and other biomass applications. Applicable models accept material commonly around 20–80 mm, with selected feedstock up to approximately 100 mm, and produce 8–12 mm material at 1–20 TPH.
This biomass hammer mill provides fine grinding after chipping, preparing uniform material for pelletizing and other biomass processing steps.
Fields not supplied are marked TBC and will be confirmed during technical communication.
| Parameter | Available information |
|---|---|
| Capacity | 1–20 TPH, depending on model and raw material |
| Typical input size | 20–80 mm |
| Maximum selected input size | Approximately 100 mm, subject to raw material |
| Output size | Approximately 8–12 mm |
| Power | Electric motor; selected by model |
Material is fed into the machine through the selected feeding system. The processing unit reduces or conditions the material, and the finished product is discharged to the next step. The actual rotor, screen, conveying and power arrangement depends on the selected model.
The hammer mill normally follows primary chipping and prepares material for pelletizing. Feed that is too large, wet or inconsistent reduces stable output, so the selected screen, motor and conveying arrangement are based on the actual material. Dust collection and safe material transfer should be planned with the grinder rather than added later.
Confirm typical and maximum chip dimensions after primary crushing.
State the required 8–12 mm range or other downstream specification.
Include feeding, discharge, dust control and connection to the pellet process.
Contact us if your application needs a different process or configuration.
Wood chips, Prepared wood pieces, Small wood residues, Selected biomass materials
1–20 TPH, depending on model and raw material
The electric wood hammer mill processes prepared wood pieces and chips into uniform wood powder for pellet production and other biomass applications. Applicable models accept material commonly around 20–80 mm, with selected feedstock up to approximately 100 mm, and produce 8–12 mm material at 1–20 TPH.
Send raw material photos or video, maximum size, moisture, hourly capacity, final product, country and WhatsApp or email.
Send photos or video of your raw material together with the required capacity and final product.
